yelkenli
Calcite | Level 5

I have the below code and some example data. The resulting sgplot line graph shows only the variable value of the first series statement (in this case the _best), in the legend. I would like the legend to show both best and worst group variable values. Any suggestions?



proc sgplot data=best_worst_stats ;
by cat_name;
title "Trend of median over week for #byval1";
series x=fiscal_wk y=median_best / group=prod_best;
series x=fiscal_wk y=median_worst / group=prod_worst;

run;

some example data

fiscal_wkcat_namewpfwprod_bestmedian_bestprod_worstmedian_worst
202126soap20212615902339.8219690732.72
202127soap20212715902319.2519690721.02
202128soap20212815902325.35196907127.36
202129soap20212915902327.7819690780.6
202130soap20213015902323.3719690747.71
202131soap20213115902314.8719690782.72
202132soap20213215902329.08196907144.06
202133soap20213315902322.7196907102.94
202126shampoo20212645837221.991206423.19
202127shampoo20212745837221.8891206434.98
202128shampoo20212845837226.3191206450.86
202129shampoo20212945837224.291206428.21
202130shampoo20213045837224.7891206427.66
202131shampoo20213145837224.8791206438.59
202132shampoo2021324583723691206482.19
202133shampoo20213345837218.291206435.8



get






want




1 ACCEPTED SOLUTION

Accepted Solutions
DanH_sas
SAS Super FREQ

In two separate legends:

proc sgplot data=best_worst_stats ;
by cat_name;
title "Trend of median over week for #byval1";
series x=fiscal_wk y=median_best / group=prod_best name="best";
series x=fiscal_wk y=median_worst / group=prod_worst name="worst";
keylegend "best" / position=bottomleft;
keylegend "worst" / position=bottomright;
run;

In the same legend:

proc sgplot data=best_worst_stats ;
by cat_name;
title "Trend of median over week for #byval1";
series x=fiscal_wk y=median_best / group=prod_best name="best";
series x=fiscal_wk y=median_worst / group=prod_worst name="worst";
keylegend "best" "worst";
run;

View solution in original post

2 REPLIES 2
DanH_sas
SAS Super FREQ

In two separate legends:

proc sgplot data=best_worst_stats ;
by cat_name;
title "Trend of median over week for #byval1";
series x=fiscal_wk y=median_best / group=prod_best name="best";
series x=fiscal_wk y=median_worst / group=prod_worst name="worst";
keylegend "best" / position=bottomleft;
keylegend "worst" / position=bottomright;
run;

In the same legend:

proc sgplot data=best_worst_stats ;
by cat_name;
title "Trend of median over week for #byval1";
series x=fiscal_wk y=median_best / group=prod_best name="best";
series x=fiscal_wk y=median_worst / group=prod_worst name="worst";
keylegend "best" "worst";
run;
DanH_sas
SAS Super FREQ

Let me explain the behavior you saw:

When a plot request has a GROUP variable, the automatic legend in SGPLOT and SGPANEL displays only the first grouped plot in the legend. If no group variables are present, all plots are added to the legend by default. However, you can alway override the default legend behavior by naming your plot overlays and adding them to one or more legends.
