tarthur
Calcite | Level 5

I’ve got some sas code that generates html which contains an sgplot with drillable data points.  When clicking on a line marker, it runs code in sas job execution.  This all works fine in studio.  Now I’m trying to run it in sas job execution and I can’t get the output to appear.  There are no errors in the log.  I think I’m just not specifying the correct job definition parameters.  Can you advise?  Also, would I leave off the ods html and ods graph statements in my code?



Here are the ods statements which I currently have commented out:

/* ods html device=png style=htmlblue newfile=page; */

/* ods graphics / reset imagemap=yes height=4in width=7in outputfmt=png; */



Here are the job definition parameters:

_action=wait

_ODSSTYLE=HTMLBlue

_OUTPUT_TYPE=html

_ODSDEST=html

_ODS_DEVICE=png



I get the html page with a missing icon for the sgplot output.



%jesbegin is generating these ods statements:

ods graphics on / outputfmt=png;
ods html style=HTMLBlue file=_webout;
4 REPLIES 4
ChrisNZ
Tourmaline | Level 20

Try option

ods html style=HTMLBlue file=_webout gpath=;
GPatel
Pyrite | Level 9

All:

I have SAS Code below, and upon SAS Job Execution, it doesn't render sgplot image.



ods graphics on / outputfmt=png;
ODS HTML style=HTMLBlue file=_webout gpath= _ODSOPTIONS = options(BITMAP_MODE='inline');
 proc sgplot data=xxx  ;

title; footnote;

by year;

  xaxis type=linear min=&min_y. max=&max_y. values=(&min_y. to &max_y. by 1);

series x=time y=estrips / name="mrfss" lineattrs=(thickness=1.85 color=black) markers markerattrs=(size=3.5px color=black) break;
series x=time y=lower_eff / name="mrfss_ci" lineattrs=(thickness=1.7 pattern=ShortDash color=ligr) break legendlabel="95% Confidence Interval" markers markerattrs=(symbol=x size=4px color=gray);
series x=time y=upper_eff / lineattrs=(thickness=1.7 pattern=ShortDash color=ligr) break legendlabel=" " markers markerattrs=(symbol=x size=4px color=gray);



yaxis offsetmin=0 ;

run;

ods html close;
ods graphics off;



I am getting




FredrikHansson
Obsidian | Level 7

I'm sorry if I missled you.

"_ODSOPTIONS" is a parameter that must be submitted to the JobExecution job. The parameter will be handled by the %JESBEGIN-macro.

%JESBEGIN macro will generate a ods-statement for you. To avoid confusion I would remove the ods-statement from your code.



The code below works for me.
I call the job with the parameter _ADDJESBEGINENDMACROS set to "false" to prevent %JESBEGIN from executing before my own code. Then I call %JESBEGIN from within my code to leverage the functionality within the macro.



Tip: Parameters can be set in job properties.

Tip2: Set the _DEBUG-parameter to true to see what code is generated from %JESBEGIN.



* Job must be called with parameter _ADDJESBEGINENDMACROS set to "false"	;


%let _ODS_DEVICE = png;
%let _ODSOPTIONS = options(BITMAP_MODE='inline');


options mprint;
%JESBEGIN;
options nomprint;

title; footnote;
proc sgplot data=sashelp.class;
 scatter x=height y=weight;
run;

%JESEND;
FredrikHansson
Obsidian | Level 7

Try setting:

_ODSOPTIONS = options(BITMAP_MODE='inline')


This option will convert your binary picture into a BASE64-encoded string that is included into the HTML. The pictures are not stored as separate binary files.
